Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 10 Version 1.2 - June 2004
FINE
GRIND
SPINDLE
Up/Down
Movement:
U
H
⇑
⇓
Rotational
Movement:
-
+
START/
STOP
The buttons on the fine grind spindle icon, located at the
right of the menu screen and just below the bridge icon,
permit manual control of up and down movement and
rotation of the fine grind spindle.
Touch the U button to move the fine grind spindle to its up
position.
Touch the H button to move the fine grind spindle to its
hover position.
Touch the Up Arrow button to move the fine grind spindle
up at a rate of 0.1 microns. Use the Up Arrow in
combination with the Factor buttons (see below) to move the
fine grind spindle up in larger increments.
Touch the Down Arrow button to move the fine grind
spindle down at a rate of 0.1 microns. Use the Down Arrow
in combination with the Factor buttons (see below) to move
the fine grind spindle down in larger increments.
Touch the Minus button to decrease the spindle speed by 1
revolution per minute. Use the Minus button in
combination with the Factor buttons (see below) to decrease
the speed of the fine grind spindle by larger increments.
Touch the Plus button to increase the spindle speed by 1
revolution per minute. Use the Plus button in combination
with the Factor buttons (see below) to increase the speed of
the fine grind spindle by larger increments.
Touch the START button to start rotation of the fine grind
spindle. Touch the STOP button to stop rotation.
