Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 11
LEFT WORK
CHUCK
Rotational
Movement:
-
+
START/
STOP
The buttons on the left work chuck icon, located at the left
side of the menu screen and just below the coarse spindle
icon, permit manual control of chuck rotation.
Touch the Minus button to decrease the chuck speed by 1
revolution per minute. Use the Minus button in
combination with the Factor buttons (see below) to decrease
the speed of the left work chuck by larger increments.
Touch the Plus button to increase the chuck speed by 1
revolution per minute. Use the Plus button in combination
with the Factor buttons (see below) to increase the speed of
the left work chuck by larger increments.
Touch the START button to start rotation of the left work
chuck.
Touch the STOP button to stop rotation.
RIGHT
WORK
CHUCK
Rotational
Movement:
-
+
START/
STOP
The buttons on the right work chuck icon, located at the right
side of the menu screen and just below the fine spindle icon,
permit manual control of chuck rotation.
Touch the Minus button to decrease the chuck speed by 1
revolution per minute. Use the Minus button in
combination with the Factor buttons (see below) to decrease
the speed of the right work chuck by larger increments.
Touch the Plus button to increase the chuck speed by 1
revolution per minute. Use the Plus button in combination
with the Factor buttons (see below) to increase the speed of
the right work chuck by larger increments.
Touch the START button to start rotation of the right work
chuck. Touch the STOP button to stop rotation.
