Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 18 Version 1.2 - June 2004
Notes on Output Control
The Output Control section of the table below lists machine components and the
controls available on their associated drop down menus.
• Options labels on drop down menus change to display the current state of the
component.
For example, if the spin/rinse drop down menu displays "Spindle Down", the
spin/rinse station spindle is currently in its down position. To move the spindle to
its up position, touch the "Spindle Down" button. The machine will respond by
moving the spindle Up and changing the button label to "Spindle Up".
• Option labels on drop down menus are displayed in green if the related sensor
recognizes the position.
• Open output control drop down menus must be closed before you can "Quit" the
Output Control/Input Status menu screen.
