Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 19
Buttons,
Submenus,
and Icons
Function(s)
QUIT
Touch the QUIT button to return to the Machine
Maintenance menu.
Output Control
LEFT WORK CHUCK
Coolant ON/OFF
Backflush ON/OFF
Blowoff ON/OFF
Vacuum ON/OFF
Probe UP/DOWN
Grind Seal DEflate/
INflate
Clean Chuck Cycle
Close
Touch the left work chuck icon to display the
left work chuck drop down menu, listing the
selections shown below:
Touch to turn coolant on or off to the left work
chuck, provided the bridge is positioned over the
chuck.
Touch to turn backflush on or off to the left
work chuck.
Touch to turn blowoff on or off to the left work
chuck.
Touch to turn vacuum on or off to the left work
chuck.
Touch to move the left probe up or down.
Touch to deflate or inflate the left grind seal.
Touch to activate the left work chuck cleaning
cycle.
Touch to close the drop down menu.
