Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 20 Version 1.2 - June 2004
RIGHT WORK CHUCK
Coolant ON/OFF
Backflush ON/OFF
Blowoff ON/OFF
Vacuum ON/OFF
Probe UP/DOWN
Grind Seal DEflate/
INflate
Clean Chuck Cycle
Close
Touch the right work chuck icon to display the
right work chuck drop down menu, listing the
button selections shown below:
Touch to turn coolant on or off to the right work
chuck, provided the bridge is positioned over the
chuck.
Touch to turn backflush on or off to the right
work chuck.
Touch to turn blowoff on or off to the right
work chuck.
Touch to turn vacuum on or off to the right
work chuck.
Touch to move the right probe up or down.
Touch to deflate or inflate the right grind seal.
Touch to activate the right work chuck cleaning
cycle.
Touch to close the drop down menu.
LEFT CHUCK
CONDITIONER
Brush Arm
UP/DOWN
Brush Arm
CW/CCW
Brush Rotate
ON/OFF
Brush Arm
Downforce ON/OFF
Close
Touch the left chuck conditioner icon to display
the left chuck conditioner drop down menu,
listing the button selections shown below:
Touch to move the left conditioning brush arm
up or down.
Touch to rotate the left conditioning brush arm
clockwise or counterclockwise.
Touch to start or stop rotation of the left
conditioning brush arm.
Touch to turn downforce on or off for the left
conditioning brush arm.
Touch to close the drop down menu.
