Strasbaugh nTellect 7AF - Page 437

Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 21
RIGHT CHUCK
CONDITIONER
Brush Arm
UP/DOWN
Brush Arm
CW/CCW
Brush Rotate
ON/OFF
Brush Arm
Downforce ON/OFF
Close
Touch the right chuck conditioner icon to
display the right chuck conditioner drop down
menu, listing the button selections shown below:
Touch to move the right conditioning brush arm
up or down.
Touch to rotate the right conditioning brush arm
clockwise or counterclockwise.
Touch to start or stop rotation of the right
conditioning brush arm.
Touch to turn downforce on or off for the right
conditioning brush arm.
Touch to close the drop down menu.
PRE-ALIGNER
Vacuum ON/OFF
Close
Touch the pre-aligner icon to display the pre-
aligner drop down menu, listing the button
selections shown below:
Touch to turn vacuum on or off to the pre-
aligner.
Touch to close the drop down menu.
