Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 31
To enter a new calibration value for the variable displayed in the Variable Label box:
Operator Action Explanation/Screen Display
1. New Value
box At the Machine Setup Entry menu, touch the "New
Value" entry box to select it.
An entry cursor (" | ") appears in the box.
2. 100.000 <Enter> Using the keyboard, type the new value (for example,
"100.000") in the entry box.
Correct errors by retyping.
Press the Enter key to confirm.
The computer transfers the new value to the "Present
Value" box, updating the Present Value displayed.
3. QUIT At the Machine Setup Entry menu, touch the "QUIT"
button.
4. Yes Touch the "Yes" button at the Save Data message to
save your entries before returning to the Machine
Maintenance menu.
3. OK Touch the "OK" button to confirm.
The data is saved, and the Machine Maintenance
menu is then displayed.
