LEFT/RIGHT GRIND CHAMBER SEALS
Solenoid
No. Component Name
Location/
Drawing No. Setting Goals
1A
7A
Left Grind Chamber Seal
Right Grind Chamber Seal
Regulators and
Gauges: Door 14
Panel
Drawing: 224038
Pressure: 20 PSI
WARNING: Do NOT set the regulators to exceed 20 PSI. To do so may
destroy the seals.
Procedure:
• Turn the knob on the regulator until the pressure gauge reads
20 PSI.
