Strasbaugh nTellect 7AF - Page 473

Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 13
LEFT/RIGHT CHUCK CONDITIONING ARMS ENGAGE
Solenoid
No. Component Name
Location/
Drawing No. Setting Goals
3
9
Left Chuck Conditioning
Arm Engage
Right Chuck Conditioning
Arm
Engage
Regulators and
Gauges: Door 14
Panel
Drawing: 224038
Pressure: 40 PSI
Procedure:
• Turn the knob on the regulator until the pressure gauge reads 40 PSI.
LEFT/RIGHT CHUCK CONDITIONING ARMS BRUSH ROTATION
Solenoid
No. Component Name
Location/
Drawing No. Setting Goals
4
10
Left Chuck Conditioning
Arm Brush Rotation
Right Chuck Conditioning
Arm
Brush Rotation
Regulators and
Gauges: Door 14
Panel
Drawing: 224038
not regulated
Procedure:
• None required.
