Strasbaugh nTellect (Model 7AF) Wafer Grinder
13 - 14 Version 1.2 - June 2004
LEFT/RIGHT CHUCK CONDITIONING ARMS DOWNFORCE
Solenoid
No. Component Name
Location/
Drawing No. Setting Goals
5
11
Left Chuck Conditioning
Arm Downforce
Right Chuck Conditioning
Arm
Downforce
Regulators and
Gauges: Door 14
Panel
Drawing: 224038
Pressure: 60 PSI
Procedure:
• Turn the knob on the regulator until the pressure gauge reads 60 PSI.
AUTOMATIC LUBRICATOR
Solenoid
No. Component Name
Location/
Drawing No. Setting Goals
13 Automatic Lubricator
Valve: Door 14
Panel
Drawing: 224038
not regulated
Procedure:
• None required.
