Strasbaugh nTellect (Model 7AF) Wafer Grinder
13 - 36 Version 1.2 - June 2004
D.I. WATER
LEFT WORK CHUCK CUTTING WATER
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
18
and
1VAL
Left Work Chuck Cutting
Water
Sol. 18 Valve only:
Door 14 Panel
Sol. 1VAL valve and
Regulator: Door 14
Panel
Gauge: "LEFT
Chuck Coolant"
value displayed at
status area of
Machine
Maintenance menu
(computer screen).
Drawing: 224038
not regulated
Flow: 2.0 GPM
Note: If both the
left and right chuck
coolant valves are
turned on at the
same time, the flow
rate may drop as low
as 1.5 GPM.
Procedure for Setting Pressure:
1. Before you begin:
a. Following the procedures found in the Basic Operation section of the
Operator Functions chapter of this manual, power up and home the
machine.
b. Move the monitor to a position such that the screen may be viewed from
the left side of the machine.
