Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 37
2. At the Machine Maintenance menu, move the bridge to its center position:
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. C Touch the "C" button, located at the upper
center of the bridge icon, to move the bridge to
its center position.
3. At the Output Control/Input Status menu, INflate the left grind seal and turn
coolant ON to the left work chuck:
Touch to Select Explanation/Screen Display
a. Inputs/Outputs At the Machine Maintenance menu screen, touch
the "Inputs/Outputs" button to select the Output
Control/Input Status menu.
Displays:
Output Control/Input Status menu
To Next Page
