Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 39
5. At the Output Control/Input Status menu, DEflate the left grind seal and turn
coolant OFF to the left work chuck:
Touch to Select Explanation/Screen Display
a. Inputs/Outputs At the Machine Maintenance menu screen, touch
the "Inputs/Outputs" button to select the Output
Control/Input Status menu.
Displays:
Output Control/Input Status menu
b. Left Work Chuck
icon Touch the "Left Work Chuck
icon", located in the Output Control section of
the menu, to display the Left Work Chuck drop
down menu.
(Right Work Chuck
icon)
c. Coolant ON/OFF Touch the "Coolant ON/OFF" button until
Coolant OFF is displayed.
d. Grind Seal
DEflate/INflate Touch the "Grind Seal DEflate/INflate" button
until Grind Seal DEflate is displayed.
e. Close Touch the "Close" button to close the drop
down menu.
f. Quit Touch the "Quit" button to return to the
Machine Maintenance menu.
g. Quit At the Machine Maintenance menu, touch the
"Quit" button to return to the Main menu.
To Next Page
