Strasbaugh nTellect (Model 7AF) Wafer Grinder
13 - 40 Version 1.2 - June 2004
RIGHT WORK CHUCK CUTTING WATER
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
22
and
2VAL
Right Work Chuck Cutting
Water
Sol. 22 Valve only:
Door 14 Panel
Sol. 2VAL valve and
Regulator: Door 14
Panel
Gauge: "RIGHT
Chuck Coolant"
value displayed at
status area of
Machine
Maintenance menu
(computer screen).
Drawing: 224038
not regulated
Flow: 2.0 GPM
Note: If both the
left and right chuck
coolant valves are
turned on at the
same time, the flow
rate may drop as low
as 1.5 GPM.
Procedure for Setting Pressure:
• Repeat as for Left Work Chuck (above), substituting "right" for "left" and
selections shown in parentheses where appropriate.
