Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 41
LEFT/RIGHT WORK CHUCK D.I. WATER BACKFLUSH
Notes:
• Chuck backflush and blow off must always be readjusted whenever you
change to a work chuck with a pore size different from the one previously
installed.
• Chuck D.I. water backflush and air blow off are set together. The details below
provide steps for making both adjustments during one procedure. Refer to Blow
Off, below in this chapter, for the adjustment summary chart for Left/Right
Work Chuck Air Blow Off.
• Blow off will increase water flow through the chuck. Thus, only a minimal amount
of D.I. water--approximately one clockwise turn--is required.
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
19
23
Left Work Chuck
D.I. Water Backflush
Right Work Chuck
D.I. Water Backflush
Regulators: Door 14
Panel
no gauge
Drawing: 224038
Pressure: Set to
produce gentle, even
water flow through
the work chuck--
water should flow
very quietly, pouring
off evenly all around
the chuck. Only
minimal amount of
water is required--
approximately 1
clockwise turn.
Note: Always
readjust the chuck
backflush and blow
off whenever you
change to a work
chuck with a pore
size different from
the one previously
installed.
