Strasbaugh nTellect (Model 7AF) Wafer Grinder
13 - 42 Version 1.2 - June 2004
Procedure for Setting Pressure:
Left Work Chuck D.I. Water Backflush and Air Blow Off
1. Following the procedures found in the Basic Operation section of the Operator
Functions chapter of this manual, power up and home the machine.
2. Position the bridge as needed.
• For the left work chuck, move the
to its right position.
• For the right work chuck, move the bridge to its left position.
To adjust the left work chuck backflush and blow off, move the bridge to its
right position:
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. R Touch the "R" button, located at the upper left
of the menu screen, to move the bridge to its
right position.
(L = left)
To Next Page
