Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 45
7. At the Output Control/Input Status menu, turn blow off and backflush OFF to
the left work chuck:
Touch to Select Explanation/Screen Display
a. Inputs/Outputs At the Machine Maintenance menu screen, touch
the "Inputs/Outputs" button to select the Output
Control/Input Status menu.
Displays:
Output Control/Input Status menu
b. Left Work Chuck
icon Touch the "Left Work Chuck
icon", located in the Output Control section of
the menu, to display the Left Work Chuck drop
down menu.
(Right Work Chuck
icon)
c. Blow off ON/OFF Touch the "Blow off ON/OFF" button until
Blow off OFF is displayed.
d. Backflush ON/OFF Touch the "Backflush ON/OFF" button until
Backflush OFF is displayed.
e. Close Touch the "Close" button to close the drop
down menu.
f. Quit Touch the "Quit" button to return to the
Machine Maintenance menu.
g. Quit At the Machine Maintenance menu, touch the
"Quit" button to return to the Machine
Maintenance menu.
Right Work Chuck D.I. Water Backflush and Air Blow Off
• Repeat as for Left Work Chuck (above), substituting "right" for "left" and
selections shown in parentheses where appropriate.
