D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Desk Operation 3-111
Operating an audio parameter on the Control Group Master influences that
parameter on all members (if that parameter has been selected in the Con-
trol Group Filter Dialog Box during Control Group Edit mode). It offsets
the member value by the move amount of the Master. Operating the
parameter on the member influences only that member’s parameter.
Control Group Edit The Control Groups are edited in the Control Group Edit Mode. This mode
is activated through the CONTROL GROUP EDIT key on the Central Fa-
cilities Unit (CFU).
On first press, the CONTROL GROUP EDIT key starts flashing to show
that an activity has been started but not yet finished. All SEL keys become
dark. Pressing the SEL key of one of the dedicated Control Group Masters
enables the editing of the corresponding Control Group. The SEL keys of
the members are lit and the SEL key of the Master flashes. The Graphic
Controller automatically activates the Control Group Filter dialog (see
below) for the selected Control Group.
When a Control Group is selected for editing (SEL keys of the members
are lit, and the SEL key of the Master flashes), member channels can be
added or removed from the Control Group by using their SEL keys. During
editing, the Control Group is not active – the setting of the Control Group
Master can be changed without influencing the members. This can be used
to adjust the offset between the Master and the Members if needed.
Editing of a control group can be concluded either by pressing the SEL key
of the master or by exiting the EDIT mode (CONTROL GROUP EDIT key
on the BSU). If you now want to proceed with editing of another control
group, first deselect (using the SEL key) the CGM you have just finished
with and then select the new control group master that you wish to edit.
