D950/Vista7 Digital Mixing System
5-56 AutoTouch+ SW V3.3 Date printed: 27.08.03
Mute: Channel Strip:
Control Modes for Mutes are not shown in a unique fashion on the channel
strip. It is not possible to determine the exact status by viewing the MUTE
STAT key locally. The unique status is shown on the CAS.
• READ or ISOLATE: MUTE STAT key is not lit.
• WRITE ENABLE: MUTE STAT key is lit (flashes when in RECORD)
• TRIM ENABLE: MUTE STAT key is lit (flashes when in RECORD)
CAS:
• READ: The MUTE READ Control Mode Activator is lit.
• WRITE ENABLE: The MUTE ABS Control Mode Activator is lit. The
MUTE STAT key lights (flashes when in RECORD).
• TRIM ENABLE: The MUTE TRIM Control Mode Activator is lit. The
MUTE STAT key lights (flashes when in RECORD).
• ISOLATE: The MUTE ISO Control Mode Activator is lit.
