Studer D950 User Manual

D950/Vista Digital Mixing System
7-32 ConfigTool SW V3.3 Date printed: 05.08.03
How to Make a Parallel Desk? Use the MultiDesk Groups checkboxes in the Edit Bus and Add Channel
dialogs in order to assign channels and buses to the two desks (operators).
The following example shows a two-operator parallel desk configuration,
whereby the inputs of the desks are independent of each other, but the
masters are common and both operators have access to the same master
buses.
The DSP capacity again is sufficient for a total of 20 input channels and
six master channels. Operator 1 sees eight input channels and all six mas-
ter channels, and Operator 2 sees twelve input channels and all six master
channels.
Common bus
and master
access
8 input channels
selected to Desk 1
8 input channels
selected to Desk 1
