Studer D950 User Manual

D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Desk Operation 3-21
Example: Pre-amplifier parameters (appear only if pre-amps are available and assigned to a channel input)
PHASE
Preamp control parameters
LINE INPUT
MIC INPUT
HIGH-PASS FILTER
(MIC input only)
PHANTOM POWER
Available operating elements and their function
SW key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
=
=
=
=
=
Input selector LINE,mutually releasing with MIC
Input gain (for details refer to section “Preamplifier
control parameters” above)
Bar display, indicates input gain
On at input gain 0 dB
LINE; label of control parameter
–9; indicates set input gain
Phantom power ON/OFF; key is illuminated if ON
no function
no function
no function
48_V; label of control parameter
Display = Indication of selected input
IN_1; input 1 (Page 1)
IN_2; input 2 (Page 2)
GEN; test generator (Page 3)
MICP; preamp control (Page 4)
AUTO
SW
1
AUTO
SW
2
AUTO
SW
3
AUTO
SW
4
MODE
AUTO STAT21
LAST MODE43
PAGE
FREEZE
MICP
48 V
HPF
MIC
LINE
=
=
=
=
=
=
=
=
=
=
High-pass filter ON/OFF; key is illuminated if ON
no function
no function
no function
LPF; label of control parameter
SW key
Rotary encoder
LED bar
Center LED
Display
SW key
Rotary encoder
LED bar
Center LED
Display
SW key
Rotary encoder
LED bar
Center LED
Display
Input selector MIC, mutually releasing with LINE
Input gain (for details refer to section “Preamplifier
control parameters” above)
Bar display, indicates input gain
On at input gain 0 dB
LINE; label of control parameter
–5; indicates set input gain
