Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
399
Firmware Version 3/4.31.37
Parameter
Description
Blend Adjustment Flow Rate
The adjusted flow rate, of the specified component, for a ratio blended
product,
Meter Real Time (RT)
Parameter
Description
Clearing Errors
Indicates that operational alarms are being cleared for
that particular meter. This process can be initiated
remotely or locally.
Clear Totals
Indicates that batch totals are clearing for a particular
flow meter.
Alarm Out
Indicates that a meter-level alarm is active.
Authorized
Indicates that a particular flow meter is authorized for
use.
Permissive
Indicates that a meter-level permissive is active.
Permissive Out
Indicates that all meter-level permissives have been
satisfied.
Side Steam On Meter
Indicates that a particular flow meter is a side-stream
meter and that it is authorized for the batch.
Meter State
Indicates the current flow state of the meter. Each state
will be represented as a numerical value (see below).
State
Numeric Value
Idle
0
Low Flow
1
High Flow
2
1
st
Trip
3
2
nd
Trip
4
Final Trip
5
Gross Delivered
The gross volume that has been delivered through the
specified meter for the current batch. Value is in whole
units.
