Managing MAC Address Table Address Configurations
Configuration Guide
133
2
Address Configurations
With MAC address table, you can:

Add static MAC address entries

Change the address aging time

Add filtering address entries

View address table entries
2.1 Using the GUI
2.1.1 Adding Static MAC Address Entries
You can add static MAC address entries by manually specifying the desired MAC address
or binding dynamic MAC address entries.

Adding MAC Addresses Manually
Choose the menu Switching > MAC Address > Static Address to load the following page.
Figure 2-1 Adding MAC Addresses Manually
Follow these steps to add a static MAC address entry:
1) Enter the MAC address, VLAN ID and select a port to bind them together.
