Configuring Layer 2 Multicast Configuring MLD Snooping
Configuring Max Groups a Port Can Join
Follow these steps to configure the maximum groups a port can join and overflow action.
1) Select a port to configure its Max Group and Overflow Action.
Select Select the port to be configured.
Max Group Enter the number of multicast groups the port can join. The valid values are from
0 to 1000.
Overflow Action Select the action towards the new multicast group when the number of multicast
groups the port joined exceeds max group.
Drop: Drop all subsequent membership report messages, and the port will not join
any new multicast groups.
Replace: Replace the existing multicast group owning the lowest multicast MAC
address with the new multicast group.
2) Click Apply.
