TP-Link T1600G-52PS User Manual

Configuring Layer 2 Multicast Configuring MLD Snooping
Configuration Guide
333
The following example shows how to configure VLAN 5 as the multicast VLAN, set the
router port time as 500 seconds and the member port time as 400 seconds:
Switch#configure
Switch(config)#ipv6 mld snooping
Switch(config)#ipv6 mld snooping multi-vlan-config 5 rtime 500
Switch(config)#ipv6 mld snooping multi-vlan-config 5 mtime 400
Switch(config)#show ipv6 mld snooping multi-vlan
Multicast Vlan:Enable
Vlan Id: 5
Router Time:500
Member Time:400
Replace Source IP:::
Static Router Port:None
Dynamic Router Port:None
Forbidden Router Port:None
Switch(config)#end
Switch#copy running-config startup-config
Configuring Static Router Port
Step 1 configure
Enter global configuration mode.
Step 2 ipv6 mld snooping multi-vlan-config [
vlan-id
] [rport interface {gigabitEthernet
port-list
|
port-channel
port-channel-id
}]
vlan-id
specifies the VLAN to be created or to be configured.
port-list
and
port-channel-id
are the static router ports in the multicast VLAN.
Step 3 show ipv6 mld snooping multi-vlan
Show the MLD snooping configuration in the multicast VLAN.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
