TP-Link T1600G-52PS User Manual

Configuration Guide 634
Configuring LLDP LLDP Configurations
LLDP Forward Message: Disabled
Tx Interval: 30 seconds
TTL Multiplier: 4
Tx Delay: 2 seconds
Initialization Delay: 2 seconds
Trap Notification Interval: 5 seconds
Fast-packet Count: 3
LLDP-MED Fast Start Repeat Count: 4
Switch(cong)#end
Switch#copy running-cong startup-cong
2.2.2 Port Config
Select the desired port and set its Admin Status, Notification Mode and the TLVs included
in the LLDP packets.
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
]
Enter interface configuration mode.
Step 3 lldp receive
(Optional) Set the mode for the port to receive LLDP packets. It is enabled by default.
Step 4 lldp transmit
(Optional) Set the mode for the port to send LLDP packets. It is enabled by default.
Step 5 lldp snmp-trap
(Optional) Enable the Notification Mode feature on the port. If it is enabled, the local device
will send Trap messages to inform the SNMP server when local information changes. It is
disabled by default.
Step 6 lldp tlv-select
(Optional) Configure the TLVs included in the outgoing LLDP packets. By default, the
outgoing LLDP packets include all TLVs.
Step 7 lldp management-address {
ip-address
}
Optional. Specify the port’s management IP address. The NMS uses management
addresses to identify the devices.
