Configuring QoS Bandwidth Control Configuration
Configuration Guide
449
Egress Rate (1-
1000000Kbps)
Configure the bandwidth for sending packets on the port. The valid values are
from 1 to 1000000 Kbps.
LAG Displays the aggregation group which the port is in.
2) Click Apply.
3.1.2 Configuring Storm Control
Choose the menu QoS > Bandwidth Control > Storm Control to load the following page.
Figure 3-2 Storm Control
Follow these steps to configure the Storm Control function:
1) Select the port(s) and configure the upper rate limit for forwarding broadcast packets,
multicast packets and UL frames.
PPS Enable or disable the PPS (Packets Per Second) mode on the port.
With PPS enabled, the upper rate limit of the broadcast, multicast and UL-frame
can only be specified in packets per second. With PPS disabled, the upper rate
limit of the broadcast, multicast and UL-frame cannot be specified in packets per
second.
