TP-Link T1600G-52PS - Adding the Port to the Specified VLAN

Configuring 802.1Q VLAN 802.1Q VLAN Configuration
Configuration Guide
157
Vlan Name Egress-rule
---- ----------- ---------------
1 System-VLAN Untagged
Switch(config-if)#end
Switch#copy running-config startup-config
2.2.3 Adding the Port to the Specified VLAN
Follow these steps to add the port to the specified VLAN:
Step 1 configure
Enter global configuration mode.
Step 2 interface {
fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
}
Enter interface configuration mode.
port| port-list
: The number or the list of the Ethernet port that you want to configure.
Step 3 switchport general allowed vlan
vlan-list
{ tagged | untagged }
Add the port to the specified VLAN, and specify its egress rule in this VLAN.
vlan-id
: The default VLAN ID of the port with the values between 1 and 4094.
tagged | untagged: Egress rule for the port.
Step 4 show interface switchport [gigabitEthernet
port
]
Verify the information of the port.
port
: Specify the ID of the port to show information.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to add the port 1/0/5 to VLAN 2, and specify its egress
rule as tagged:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#switchport general allowed vlan 2 tagged
Switch(config-if)#show interface switchport gigabitEthernet 1/0/5
Port Gi1/0/5:
PVID: 2
Member in LAG: N/A
