Appendix: Default Parameters

DiffServ
Table 5-1 DiffServ
Parameter Default Setting
Port Priority Enabled. Packets from all ports are mapped to the same TC queue.
802.1P Priority For T1600G-18TS
,
it is disabled. You can manually enable it. See Table 5-2
for Tag-id/CoS-id-TC mapping relations.
For other switches, it is enabled. See Table 5-2 for Tag-id/CoS-id-TC
mapping relations.
DSCP Priority Disabled.
For T1600G-18TS, see Table 5-4 for DSCP-TC mapping relations.
For other switches, see Table 5-3 for DSCP-CoS Mapping relations.
Schedule Mode Equ-Mode.
Table 5-2 Tag-id/CoS-id-TC Mapping
Tag-id/CoS-id TC Queues (8)
0 TC1
1 TC0
2 TC2
3 TC3
4 TC4
5 TC5
6 TC6
7 TC7
Table 5-3 DSCP-CoS Mapping
DSCP CoS-id
0~7 CoS 0
8~15 CoS 1
16~23 CoS 2
24~31 CoS 3
32~39 CoS 4
40~47 CoS 5
48~55 CoS 6
