Configuring LLDP Viewing LLDP Settings
Configuration Guide
647
4.1.2 Viewing LLDP Statistics
Choose the menu LLDP > Device Statistics > Statistics Info to load the following page.
Figure 4-3 Static Info
Follow these steps to view LLDP statistics:
1) In the Auto Refresh section, enable the Auto Refresh feature and set the Refresh Rate
according to your needs. Click Apply.
2) In the Global Statistics section, view the global statistics of the local device.
Last Update Displays the time when the statistics updated.
Total Inserts Displays the latest number of neighbors the local device has created.
Total Deletes Displays the latest number of neighbors the local device has removed.
Total Drops Displays the latest number of neighbors the local device has discarded.
Total Ageouts Displays the latest number of neighbors that have aged out on the local device.
3) In the Neighbors Statistics section, view the statistics of the corresponding port.
