Configuring Logical Interfaces Logical Interfaces Configurations
Configuration Guide
379
IP Address Mode Specify the IP address assignment mode of the interface.
None: No IP address will be assigned.
Static: Assign an IP address manually.
DHCP: Assign an IP address through DHCP .
BOOTP: Assign an IP address through BOOTP.
IP Address Specify the IP address of the interface if you choose “Static” as the IP address
assignment mode.
Subnet Mask Specify the subnet mask of the interface’s IP address.
Admin Status Enable or disable the interface’s Layer 3 capabilities.
Interface Name (Optional) Enter the name of the interface.
2) In the Interface List section, you can view the corresponding interface entry you
create.
2.1.2 Configuring IPv4 Parameters of the Interface
In
Figure 2-1
you can view the corresponding interface entry you create in the Interface
List section. On the corresponding interface entry, click Edit to load the following page and
configure the IPv4 parameters of the interface.
Figure 2-2 Configuring the IPv4 Parameters
1) In the Modify Interface section, specify an interface ID and configure relevant
parameters for the interface according to your actual needs. Then click Apply.
Interface ID Select an interface type and enter the ID of the interface.
