Configuration Guide 283
Configuring Layer 2 Multicast IGMP Snooping Configurations
Figure 2-11 Static Member Port
Configuring Static Member Port
Follow these steps to configure static member port.
1) Enter the Multicast IP and VLAN ID. Specify the Static Member Port.
Multicast IP Specify the multicast group that the static member is in.
VLAN ID Specify the VLAN that the static member is in.
Forward Port Specify one or more ports to be the static member port in the multicast group.
Without aging, the static member port receives all multicast data sent to this
multicast group.
2) Click Create.
Viewing IGMP Static Multicast Groups
You can search IGMP static multicast entries by using Multicast IP, VLAN ID or Forward
Port as the Search Option.
Static Multicast IP Table displays details of all IGMP static multicast groups.
