Configuration Guide 82

Managing Physical Interfaces Port Mirror Configuration

Port Mirror Configuration

3.1 Using the GUI

Choose the menu Switching > Port > Port Mirror to load the following page.

Figure 3-1 Mirror Session List

The above page displays a mirror session, and no more session can be created. Click Edit

to configure this mirror session on the following page.
