Configuration Guide 380
Configuring Logical Interfaces Logical Interfaces Configurations
IP Address Mode Specify the IP address assignment mode of the interface.
None: No IP address will be assigned.
Static: Assign an IP address manually.
DHCP: Assign an IP address through DHCP .
BOOTP: Assign an IP address through BOOTP.
IP Address Specify the IP address of the interface if you choose “Static” as the IP address
assignment mode.
Subnet Mask Specify the subnet mask of the interface’s IP address.
Admin Status Enable or disable the interface’s Layer 3 capabilities.
Interface Name (Optional) Enter the name of the interface.
2) In the Secondary IP Create section, configure the secondary IP for the specified
interface which allows you to have two logical subnets using one physical subnet. Then
click Create.
3) In the Secondary IP List section, you can view the corresponding secondary IP entry
you create.
2.1.3 Configuring IPv6 Parameters of the Interface
In
Figure 2-1
, you can view the corresponding interface entry you create in the Interface
List section. On the corresponding interface entry, click Edit IPv6 to load the following
page and configure the IPv6 parameters of the interface.
