Configuration Guide 428
Configuring ARP ARP Configurations
2
ARP Configurations
With ARP configurations, you can:

View dynamic and static ARP entries.

Add or delete static ARP entries.
2.1 Using the GUI
2.1.1 Viewing the ARP Entries
The ARP table consists of two kinds of ARP entries: dynamic and static.

Dynamic Entry: Automatically learned and will be deleted after aging time.

Static Entry: Added manually and will be remained unless modified or deleted manually.
Choose the menu Routing > ARP > ARP Table to load the following page.
Figure 2-1 Viewing the ARP Entries
Interface Displays the network interface of an ARP entry.
IP Address Displays the IP address of an ARP entry.
MAC Address Displays the MAC address of an ARP entry.
Type Displays the type of an ARP entry.
STATIC: A static ARP entry that will always be remained.
DYNAMIC: A dynamic ARP entry that will be deleted after aging time.
