Configuring Layer 2 Multicast IGMP Snooping Configurations
Configuration Guide
279
Figure 2-8 Profile Binding
Binding Profile and Member Ports
Follow these steps to bind the profile to the port.
1) Select the port to be bound, and enter the Profile ID in the Profile ID column.
Select Select the port to be bound.
Port Displays the port number.
Profile ID Enter the profile ID you create to bind the profile to the port. One port can only be
bound to one profile.
ClearBinding Click to clear the binding between the profile and the port.
2) Click Apply.
Configuring Max Groups a Port Can Join
Follow these steps to configure the maximum groups a port can join and overflow action.
1) Select a port to configure its Max Group and Overflow Action.
Select Select the port to be configured.
