Configuration Guide 436
Configuring QoS DiffServ Configuration
2.1 Using the GUI
2.1.1 Configuring Priority Mode
The instructions of the three priority modes are described respectively in this section.

Configuring 802.1P Priority
Choose the menu QoS > DiffServ > 802.1P Priority to load the following page.
Figure 2-1 802.1P/CoS Mapping
Follow these steps to configure the 802.1P Priority:
1) Enable 802.1P Priority and click Apply.
802.1P Priority Enable the 802.1P Priority globally.
For T1600G-18TS, the 802.1P priority feature is disabled by default. You can
manually enable it.
For other T1600G series switches, the 802.1P priority feature is enabled by
default and cannot be disabled.
2) Configure the Tag-id/CoS-id-TC mapping relations.
