TP-Link T1600G-52PS User Manual

Configuring Spanning Tree MSTP Configurations
Configuration Guide
231
Step 4 name
name
Configure the region name of the region.
name
: Specify the region name, used to identify an MST region. The valid values are from 1 to
32 characters.
Step 5 revision
revision
Configure the revision level of the region.
revision:
Specify the revision level of the region. The valid values are from 0 to 65535.
Step 6 instance
instance-id
vlan
vlan-id
Configure the VLAN-Instance mapping.
instance-id
: Specify the Instance ID. The valid values are from 1 to 8.
vlan-id
: Specify the VLAN mapped to the corresponding instance.
Step 7 show spanning-tree mst { configuration [ digest ] | instance
instance-id
[ interface [
fastEthernet
port
| gigabitEthernet
port
| port-channel
lagid
] ] }
(Optional) View the related information of MSTP Instance.
digest
: Display digest calculated by instance-vlan map.
instance-id
: Specify the Instance ID desired to view, ranging from 1 to 8.
port:
Specify the port number.
lagid:
Specify the ID of the LAG.
Step 8 end
Return to privileged EXEC mode.
Step 9 copy running-config startup-config
Save the settings in the configuration file.
This example shows how to create an MST region, of which the region name is R1, the
revision level is 100 and VLAN 2-VLAN 6 are mapped to instance 5:
Switch#configure
Switch(config)#spanning-tree mst configuration
Switch(config-mst)#name R1
Switch(config-mst)#revision 100
Switch(config-mst)#instance 5 vlan 2-6
Switch(config-mst)#show spanning-tree mst configuration
Region-Name : R1
Revision : 100
