Configuring QoS DiffServ Configuration
Configuration Guide
447
Step 6 copy running-config startup-config
Save the settings in the configuration file.
Note:
With ACL Redirect feature, the switch maps all the packets that meet the configured ACL rules to
the new TC queue, regardless of the mapping relations configured in this section.
The following example shows how to configure the schedule mode as WRR, with the weight
values of TC0 to TC7 as 4, 7, 10, 13,16,19,22,25:
Switch#configure
Switch(config)#qos queue mode wrr
Switch(config)#qos queue weight 0 4
Switch(config)#qos queue weight 1 7
Switch(config)#qos queue weight 2 10
Switch(config)#qos queue weight 3 13
Switch(config)#qos queue weight 4 16
Switch(config)#qos queue weight 5 19
Switch(config)#qos queue weight 6 22
Switch(config)#qos queue weight 7 25
Switch(config)#show qos queue mode
---------------------+--------------------------------------------------------------------------
Schedule Mode: WRR | Weight: TC0=4 TC1=7 TC2=10 TC3=13 TC4=16 TC5=19
TC6=22 TC7=25
---------------------+--------------------------------------------------------------------------
Switch(config)#end
Switch#copy running-config startup-config
