Configuration Guide 470
Configuring Voice VLAN Voice VLAN Configuration
Step 13 end
Return to privileged EXEC mode.
Step 14 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to set port 1/0/1 in manual voice VLAN mode. Configure
the switch to forward voice traffic with an IEEE 802.1p priority of 5 and to transmit only
voice traffic whose resource MAC address matches an OUI address in the voice VLAN :
Switch#configure
Switch(config)#vlan 10
Switch(config-vlan)#name VoiceVLAN
Switch(config-vlan)#exit
Switch(config)#voice vlan priority 5
Switch(config)#voice vlan 10
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#switchport voice vlan mode manual
Switch(config-if)#switchport voice vlan security
Switch(config-if)#switchport general allowed vlan 10 untagged
Switch(config-if)#show voice vlan
Voice VLAN status: Enabled
VLAN ID: 10
Aging Time: 1440
Voice Priority: 5
Switch(config-if)#show voice vlan switchport
Port Auto-mode Security State LAG
------ ------------ ------------ ------------ ------
Gi1/0/1 Manual Enabled Active N/A
Gi1/0/2 Auto Disabled Inactive N/A
Gi1/0/3 Auto Disabled Inactive N/A
......
Switch(config-if)#end
Switch#copy running-config startup-config
