Configuration Guide 524
Configuring ACL ACL Configurations
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create Standard-IP ACL 600, and configure Rule 1 to
permit packets with source IP address 192.168.1.100:
Switch#configure
Switch(config)#access-list create 600
Switch(config)#rule 1 permit sip 192.168.1.100 smask 255.255.255.255
Switch(config)#show access-list 600
Standard IP access list 600
rule 1 permit sip 192.168.1.100 smask 255.255.255.255
Switch(config)#end
Switch#copy running-config startup-config

Configuring the Extend-IP ACL
Step 1 configure
Enter global configuration mode
Step 2 access-list create
access-list-num
Create an Extend-IP ACL
access-list-num:
Enter an ACL ID. The ID ranges from 1500 to 2499.
