Configuration Guide 573
Configuring Network Security 802.1X Configuration
Choose the menu Network Security > AAA > Server Group to load the following page.
Figure 6-3 Adding a Server Group
Follow these steps to create a protocol template:
1) In the Add New Server Group section, specify the name and server type for the new
server group, and click Add.
Server Group: Specify the name of the new server group.
Server Type: Select the type of the server group as RADIUS.
2) Select the newly added group, and click edit in the Operation column.
Figure 6-4 Edit the Group
3) Select the server to be added to the group from the Server IP drop-down list . Then
click Add to add this server to the server group.
