Configuration Guide 606
Configuring Network Security Configuration Examples
Figure 8-3 Port Config
3) Choose the menu Network Security > IP-MAC Binding > Manual Binding to load the
following page. Enter the host name, IP address, MAC address and VLAN ID of User 3,
select ARP Detection as the protect type, and select port 1/0/3 on the panel. Click Bind.
Figure 8-4 Manual Binding
4) Choose the menu Network Security > IP-MAC Binding > Binding Table to load the
following page. Select Source type as All, and click Search to view all the entries that
have been bound.
