Configuration Guide 624

Configuring Network Security Appendix: Default Parameters

Table 9-3 ARP Inspection

Parameter Default Setting

ARP Detect

ARP Detect Disable

Trusted Port None

ARP Defend

Defend Disable

Speed 15 pps

ARP Statistics

Auto Refresh Disable

Refresh Interval 5 seconds

Table 9-4 DoS Defend

Parameter Default Setting

DoS Defend Disable

Table 9-5 802.1X

Parameter Default Setting

Global Config

802.1X Authentication Disable

Auth Method EAP

Handshake Enable

Guest VLAN Disable

Accounting Disable

Quiet Feature

Quiet Feature Disable

Quiet Period 10 seconds

Retry Times 3
