Configuring LLDP Viewing LLDP Settings
Configuration Guide
645
Follow these steps to view the local information:
1) In the Auto Refresh section, enable the Auto Refresh feature and set the Refresh Rate
according to your needs. Click Apply.
2) In the Local Info section, select the desired port and view its associated local device
information.
Local Interface Displays the local port ID.
Chassis ID
Subtype
Displays the Chassis ID type.
Chassis ID Displays the value of the Chassis ID.
Port ID Subtype Displays the Port ID type.
Port ID Displays the value of the Port ID.
TTL Specify the amount of time the neighbor device should hold the received
information before discarding it.
Port Description Displays the description of the local port.
System Name Displays the system name of the local device.
System
Description
Displays the system description of the local device.
System
Capabilities
Supported
Displays the supported capabilities of the local system.
System
Capabilities
Enabled
Displays the primary functions of the local device.
Management
Address
Displays the management address of the local device.
