Humphrey Field
Analyzer II-
i
series User Manual
266002
11
45640 A
T
est Patterns
F-5
Figure F
.17
Nasal Step Thresh
old T
est P
atter
n, Right
Eye
Figure F
.18 Peripheral 60
-
4 Threshold T
est Pat
tern, Right Eye
438
