3 - TORQUE SETTINGS
Frame torque settings
Part Thread (mm) Nm ±10% Tolerance Notes
Front Sprocket
Chain sprocket fixing ...... 186
*
GREASE B
Front sprocket cover screw M 6x1 6
Optical Devices
Screws securing LH/RH headlight to light assembly 6x1 6
Webasto screws 6x1 3
Screws securing studs to LH/RH light assembly ...... 8 Lock 2
Headlight assembly /steering tube screw 6x1 8
Sprayguard/headlight assembly screws 6x1 5 Lock 2
Tail light assembly screws under silencer 5x0.8 3
Tail light screw ...... 3
Screw securing tail light heat shield to silencer 6x1 8
Number plate light nut 6x1 1,5
RH/LH headlight fairing support screw 6x1 10
Headlight adjuster knob screw Self-tapping 1
Nut securing reflector support to number plate support ...... 4
Instruments
Pin securing front wiring harness to instrument panel 6x1 2,2
Front Fork
Steering head screw 8x1.25 23* Grease B
Bottom yoke screws 8x1.25 14* In sequence 1-2-1 Grease B
Steering head tube screw 8x1.25 22* Grease B
Fork end screw 8x1.25 19* Grease B - Sequence 1-2-1
Steering bearing ringnut 35x1 20 Grease B – Back off 30°
Steering damper / steering head screw 6x1 10 Lock 1
Steering head tube locating dowel 12x1 19 Grease B
BOGE steering damper ball joint (749/749S) ...... 8 Lock 3
Steering pin 37x1 * *Fully inserted with Lock 8
Steering damper support screw 6x1 8 Lock 2
Steering limit lock nut 8x1.25 18 Lock 2 (apply Loctite to nut
thread)
Screw securing steering limit plate to bottom of steering
head on 749
...... 5 Lock 2
Screw securing front brake pipe guides to RH fork leg
(749S)
4x0.7 1,3
Electrical System
Wire clamp nut on battery contact plate 5x1 5
Lower battery support bolt 5x0.8 8
Upper battery support bolt 6x1 10
Screw securing horn to bracket 6x1 10
Screw securing horn bracket to horizontal cylinder head
side cover
6x1 10
Nut securing horn to bracket 12x1 20
Starter motor nut 6x1 5 Grease B
Screw securing fuse box support to light assembly 5x10 2,5
Cable / contactor nut 6x1 4
RH switch screw ...... 1
