Ducati DARK 749 - Engine torque settings

Caratteristiche tecniche
Specifications
sezione / section
C 3
35
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Engine torque settings
Part Thread (mm) Nm Min. Max. Notes
Blow-by valve M 40x1.5 40 36 44
Mesh filter blanking cap M 32x1.5 42 38 46
Coolant intake manifold M 30x1.5 30 27 33 LOCK 6
Oil temperature sensor holder ringnut M 30x1.5 38 34 42 LOCK 4
Crankshaft gear nut M 12x1.25 190 170 209 GREASE B
Injection generator rotor nut M 24x1 270 256 284 ENGINE OIL
Crankshaft gear nut M 22x1 190 171 209 GREASE B
Oil drain plug M 22x1.5 42 38 46
Oil mesh filter M 22x1.5 42 38 46
Coolant outlet union M 22x1.5 27 25 30 LOCK 5
Engine fan thermo switch M 22x1.5 42 38 46 LOCK 4
Oil filler cap M 22x1.5 5 5 6
Fixed/mobile tensioner pin M 20x1 50 45 55 LOCK 2 or THREE
BOND 1324
Dry clutch drum nut M 20x1 190 180 200 GREASE B
Steel/aluminium crankshaft blanking cap M 20x1 15 13,5 16,5 THREE BOND 1375B
Cylinder head timing pulley nut M 17x1 71 64 78 GREASE A
Gearbox drum locator screw M 16x1.5 30 27 33
Oil filter nipple M 16x1.5 42 38 46 LOCK 2 or THREE
BOND 1324
Oil filter cartridge M 16x1.5 11 10 12 Engine oil on gasket
Mesh filter duct plug M 15x1 20 18 22 LOCK 5 or THREE
BOND 1375B
By-pass pump cap M 15x1 25 22 28 LOCK 5 or THREE
BOND 1375B
Ringnut securing timing pulleys on layshaft shaft M 15x1 71 64 78 GREASE A
Timing pulley ringnuts on cylinder heads M 15x1 71 64 78 GREASE A
Generator cover inspection plug M 15x1 20 18 22 THREE BOND 1215
Fixed tensioner bearing screw M 14x2 50 45 55 GREASE C
Sump oil intake pipe plug M 14x1.5 24 21 27 LOCK 5 or THREE
BOND 1375B
Layshaft timing shaft gear nut M 14x1 55 50 60 GREASE A
Radiator connection plug M 14x1.5 24 21 27 LOCK 5 or THREE
BOND 1375B
Radiator connection blanking plug M 14x1.5 27 24 30 LOCK 5 or THREE
BOND 1375B
Oil cooler nipple M 14x1.5 27 24 30 LOCK 5 or THREE
BOND 1375B
Pick-up sensor inspection screw M 12x1 15 13 17 LOCK 2 or THREE
BOND 1324
Ground connection screw M 12x1 18 16 19 LOCK 2 or THREE
BOND 1374
Oil temperature sensor M 12x1.5 18 16 19 LOCK 4
Coolant temperature sensor (control unit) M 12x1.5 23 20 26 LOCK 4
Spark plugs M 12x1.25 20 18 22
