Caratteristiche tecniche
Specifications
sezione / section
C 3
34
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
*
dynamic safety-critical point; locking torque tolerance within Nm ± 5%.
Notes
For product specifications and symbols, see “Product specifications” (Section A 2).
Liquid cooling
Screw securing LH side of radiator to frame 6x1 10 Grease B
Coolant hose clamps ...... 2,5
Screw securing radiator hose clamp to vertical cylinder
head
...... 1
Cable clamp bolt and nut 6x1 10
Radiator retaining pin on RH side of frame ...... 10
Water drain plug on pump cover ...... 20
Part Thread (mm) Nm ±10% Tolerance Notes
