Caratteristiche tecniche
Specifications
sezione / section
C 3
33
A
B
C
D
E
F
G
H
L
M
N
P
749/749 DARK/749S Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Seat lock screw 5x0.8 5
Nut securing brackets and passenger belt to dual seat
under frame
6x1 10
Passenger belt screw 6x1 9*
Screw securing rider seat grabhandle with seat/tank/tail
guard assembly to frame
6x1 10
Air Intake Oil Breather
Clamp securing oil breather hose to breather valve ...... 1,5
Oil breather tank screw 6x1 4
Air intake funnel screw 5x0.8 5
Air intake funnel spring screw 5x0.8 3 Lock 2
Throttle body clamp ...... 2
Air box cover screw Self-tapping 2
Canister feed
Screw securing canister pipe to manifold union ...... 1,5
Screw securing canister bracket to horizontal head side
cover
6x1 10
Nuts securing canister support to bracket 6x1 10
Screw securing throttle body to air box 6x1 10
Fairings
Front fairing air scoop screw Self-tapping 8
Fixing screw on Wellnut on / lower part of RH/LH half
fairing
6x1 1,5
Screw securing upper half fairings to lower half-fairings
and baffles
5x0.8 5 Lock 2
Front fairing screw 6x1 8
RH and LH fairing support screw 6x1.5 10
LH fairing support screw 10x1 20
Single-seater tail guard screw 5x0.8 1,2 Lock 2
Front shield screw 6x1 2,5 Lock 2
RH/LH air scoop cover screw ...... 0,8
Fixing for fairing pin mounting side fairings to front fairing 5x0.8 5 Lock 2
RH/LH side fairing assembly plate screw 5x0.8 5
Stand
Side stand plate screw 10x1.5 43 Lock 5
Side stand sensor cable clamp bolt 6x1 10
Side stand pivot shaft nut ...... 19 Lock 10 (apply Grease B to
stand pivot shaft)
Stand sensor screw 6x1 10
Frame
Screw securing rear subframe to frame 8x1.25 30
Nut securing engine to frame 12x1.25 60* Grease B
Seat slide screw Self-tapping ... Lock 2
Oil cooler
Oil cooler nipple 14x1.5 23 Lock 1
Oil cooler screw 6x1 10
Oil pipe union on cooler with TWIN SEAL O-ring 16x1.5 25* Lubricate with engine oil
(Shell Advance Ultra 4)
Oil pipe union on crankcase with Twin Seal O-ring 16x1.5 25* Lubricate with engine oil
(Shell Advance Ultra 4)
Part Thread (mm) Nm ±10% Tolerance Notes
